Automotive

    Interior Components
  • Head-up Display
  • Meter Cluster
  • Center Information Display
  • Driver Monitoring System
  • Rear Seat Entertainment
  • Climate Control
  • Body, Seat Controls
Interior Components
    Exterior Components
  • Headlamp
  • LiDAR
  • On-board Charger, DC/DC Converter, Inverter unit
  • BMS
  • Telematics
  • Rear View Camera
  • Roof, Door Harness
  • Rear Lamp
Exterior Components
Head-up Display
EVAFLEX® 5-SE-G VT
One-handed auto-locking feature, high temperature (125℃), high-speed, vertical mate, 0.5 mm pitch shielded FFC/FPC connector
  • FPC
  • FFC
  • SHIELD FFC
EVAFLEX® 5-VS
Auto-locking, high temperature option (105℃), high-speed, horizontal mate, 0.5 mm pitch shielded FFC/FPC connector
  • FPC
  • FFC
  • SHIELD FFC
EVAFLEX® 5-SE
Auto-locking, horizontal mate, 0.5 mm pitch FFC/FPC connector
  • FPC
  • FFC
EVAFLEX® 5-SE VT
Auto-locking, vertical mate, 0.5 mm pitch FFC/FPC connector
  • FPC
  • FFC
Meter Cluster
EVAFLEX® 5-VS
Auto-locking, high temperature option (105℃), high-speed, horizontal mate, 0.5 mm pitch shielded FFC/FPC connector
  • FPC
  • FFC
  • SHIELD FFC
EVAFLEX® 5-SE
Auto-locking, horizontal mate, 0.5 mm pitch FFC/FPC connector
  • FPC
  • FFC
CABLINE®-CA II
Fully-shielded with mechanical lock, high-data-rate transfer, 0.4 mm pitch, horizontal mating type micro-coaxial connector
  • MICRO-COAX
  • DISCRETE WIRE
CABLINE®-VS II
Fully-shielded with mechanical lock, suitable for high-data-rate transfer (20 Gbps/lane), 0.5 mm pitch, horizontal mating type micro-coaxial connector
  • MICRO-COAX
  • DISCRETE WIRE
CABLINE®-VS
VESA standard connector, Suitable for high-data-rate transfer (20 Gbps/lane), Mechanical locking bar, 0.5 mm pitch, Horizontal mating type micro-coaxial connector
  • MICRO-COAX
  • DISCRETE WIRE
CABLINE®-CA
High-data-rate transfer, mechanical lock with shielding and multi-point ground, 0.4 mm pitch, Horizontal mating type micro-coaxial connector
  • MICRO-COAX
  • DISCRETE WIRE
Center Information Display
EVAFLEX® 5-VS
Auto-locking, high temperature option (105℃), high-speed, horizontal mate, 0.5 mm pitch shielded FFC/FPC connector
  • FPC
  • FFC
  • SHIELD FFC
EVAFLEX® 5-SE
Auto-locking, horizontal mate, 0.5 mm pitch FFC/FPC connector
  • FPC
  • FFC
MINIFLEX® 5-FF
Robust design with hold down feature, height = 2.55 mm, 0.5 mm pitch, horizontal, front flip
  • FPC
  • FFC
MINIFLEX® 5-BFN II
Robust design with hold-down feature, low profile (height = 1.0 mm), 0.5 mm pitch, horizontal, backflip
  • FPC
  • FFC
MHF® I LK
Locking solution that works with MHF I receptacles, supports up to 9 GHz, mated height of 2.9 mm max
  • MICRO-COAX
MHF® I
Supports up to 9 GHz, mated height of 2.5 mm max. and 3.0 mm max.
  • MICRO-COAX
MHF® I (4 pads receptacle)
MHF® I receptacle with additional 4th pad improves center alignment when mounted on the board by reflow, and increases solder shear force
  • MICRO-COAX
EVAFLEX® 5-HD
Fully-shielded, high-speed, auto-locking, horizontal mate, 0.5 mm pitch shielded FFC/FPC connector
  • FFC
  • FPC
  • EMI SHIELD
  • SHIELD FFC
CABLINE®-CA II
Fully-shielded with mechanical lock, high-data-rate transfer, 0.4 mm pitch, horizontal mating type micro-coaxial connector
  • MICRO-COAX
  • DISCRETE WIRE
CABLINE®-VS II
Fully-shielded with mechanical lock, suitable for high-data-rate transfer (20 Gbps/lane), 0.5 mm pitch, horizontal mating type micro-coaxial connector
  • MICRO-COAX
  • DISCRETE WIRE
CABLINE®-VS
VESA standard connector, Suitable for high-data-rate transfer (20 Gbps/lane), Mechanical locking bar, 0.5 mm pitch, Horizontal mating type micro-coaxial connector
  • MICRO-COAX
  • DISCRETE WIRE
CABLINE®-CA
High-data-rate transfer, mechanical lock with shielding and multi-point ground, 0.4 mm pitch, Horizontal mating type micro-coaxial connector
  • MICRO-COAX
  • DISCRETE WIRE
MHF®-TI
Small, robust RF connector for automotive telematics antenna, and camera sensors
  • MICRO-COAX
Driver Monitoring System
MHF®-TI
Small, robust RF connector for automotive telematics antenna, and camera sensors
  • MICRO-COAX
MHF® I LK
Locking solution that works with MHF I receptacles, supports up to 9 GHz, mated height of 2.9 mm max
  • MICRO-COAX
Rear Seat Entertainment
CABLINE®-VS II
Fully-shielded with mechanical lock, suitable for high-data-rate transfer (20 Gbps/lane), 0.5 mm pitch, horizontal mating type micro-coaxial connector
  • MICRO-COAX
  • DISCRETE WIRE
CABLINE®-SS
Narrow depth, robust, right angle vertical mate with max power delivery (AWG#34) In 0.4 mm pitch size and high temperature/humidity (autoclavable) option
  • MICRO-COAX
  • DISCRETE WIRE
CABLINE®-CA II
Fully-shielded with mechanical lock, high-data-rate transfer, 0.4 mm pitch, horizontal mating type micro-coaxial connector
  • MICRO-COAX
  • DISCRETE WIRE
CABLINE®-UM
Fully-shielded and multi-point ground, Mechanical lock, High-data-rate transfer (20 Gbps/lane), 0.4 mm pitch, Right angle vertical mating type micro-coaxial connector
  • MICRO-COAX
  • DISCRETE WIRE
CABLINE®-VS
VESA standard connector, Suitable for high-data-rate transfer (20 Gbps/lane), Mechanical locking bar, 0.5 mm pitch, Horizontal mating type micro-coaxial connector
  • MICRO-COAX
  • DISCRETE WIRE
EVAFLEX® 5-VS
Auto-locking, high temperature option (105℃), high-speed, horizontal mate, 0.5 mm pitch shielded FFC/FPC connector
  • FPC
  • FFC
  • SHIELD FFC
EVAFLEX® 5-SE
Auto-locking, horizontal mate, 0.5 mm pitch FFC/FPC connector
  • FPC
  • FFC
MHF® I LK
Locking solution that works with MHF I receptacles, supports up to 9 GHz, mated height of 2.9 mm max
  • MICRO-COAX
Climate Control
EVAFLEX® 5-VS
Auto-locking, high temperature option (105℃), high-speed, horizontal mate, 0.5 mm pitch shielded FFC/FPC connector
  • FPC
  • FFC
  • SHIELD FFC
EVAFLEX® 5-SE
Auto-locking, horizontal mate, 0.5 mm pitch FFC/FPC connector
  • FPC
  • FFC
ISH® (Horizontal Type)
High heat and vibration resistant, horizontal, SMT connector
  • DISCRETE WIRE
ISH® (Wire-to-Wire Type)
High heat and vibration resistance, wire-to-wire relay connector
  • DISCRETE WIRE
ISH® (Vertical Type)
High heat and vibration resistant, vertical SMT connector
  • DISCRETE WIRE
ISH® (Horizontal Type-Hybrid)
High heat and vibration resistant connector with hybrid (signal + power) terminals
  • DISCRETE WIRE
IARPB® (Horizontal Type)
Vibration resistant, one-piece,horizontal type board-in connector
  • DISCRETE WIRE
IARPB® (Vertical Type)
Vibration resistant, one-piece,vertical type board-in connector
  • DISCRETE WIRE
ISFIT® (Press-Fit Terminal)
Wire-to-board/board-to-board, 4-points spring contact press-fit terminal
  • POWER PIN
  • BOARD TO BOARD
MINIFLEX® 5-BFN II LK
Mechanical lock, robust design with hold-down feature, low profile (height = 1.0 mm), 0.5 mm pitch, horizontal, backflip
  • FPC
  • FFC
Body, Seat Controls
ISH® (Horizontal Type)
High heat and vibration resistant, horizontal, SMT connector
  • DISCRETE WIRE
ISH® (Wire-to-Wire Type)
High heat and vibration resistance, wire-to-wire relay connector
  • DISCRETE WIRE
ISH® (Vertical Type)
High heat and vibration resistant, vertical SMT connector
  • DISCRETE WIRE
ISH® (Horizontal Type-Hybrid)
High heat and vibration resistant connector with hybrid (signal + power) terminals
  • DISCRETE WIRE
IARPB® (Horizontal Type)
Vibration resistant, one-piece,horizontal type board-in connector
  • DISCRETE WIRE
IARPB® (Vertical Type)
Vibration resistant, one-piece,vertical type board-in connector
  • DISCRETE WIRE
Headlamp
ISH® (Horizontal Type)
High heat and vibration resistant, horizontal, SMT connector
  • DISCRETE WIRE
ISH® (Horizontal Type-Hybrid)
High heat and vibration resistant connector with hybrid (signal + power) terminals
  • DISCRETE WIRE
ISH® (Vertical Type)
High heat and vibration resistant, vertical SMT connector
  • DISCRETE WIRE
ISH® (Wire-to-Wire Type)
High heat and vibration resistance, wire-to-wire relay connector
  • DISCRETE WIRE
IARPB® (Horizontal Type)
Vibration resistant, one-piece,horizontal type board-in connector
  • DISCRETE WIRE
IARPB® (Vertical Type)
Vibration resistant, one-piece,vertical type board-in connector
  • DISCRETE WIRE
ISFIT® (Press-Fit Terminal)
Wire-to-board/board-to-board, 4-points spring contact press-fit terminal
  • POWER PIN
  • BOARD TO BOARD
LiDAR
EVAFLEX® 5-SE-G VT
One-handed auto-locking feature, high temperature (125℃), high-speed, vertical mate, 0.5 mm pitch shielded FFC/FPC connector
  • FPC
  • FFC
  • SHIELD FFC
EVAFLEX® 5-SE-G HT
One-handed auto-locking feature, high temperature (125℃), high-speed, horizontal mate, 0.5 mm pitch shielded FFC/FPC connector
  • FPC
  • FFC
  • SHIELD FFC
EVAFLEX® 5-VS
Auto-locking, high temperature option (105℃), high-speed, horizontal mate, 0.5 mm pitch shielded FFC/FPC connector
  • FPC
  • FFC
  • SHIELD FFC
EVAFLEX® 5-SE
Auto-locking, horizontal mate, 0.5 mm pitch FFC/FPC connector
  • FPC
  • FFC
MHF®-TI
Small, robust RF connector for automotive telematics antenna, and camera sensors
  • MICRO-COAX
NOVASTACK® 35-P
Robust connector with hold-down feature and Corson Alloy main contacts to transmit power lines, 0.35 mm pitch, 0.7 mm height, 2.3 mm depth
  • BOARD TO BOARD
  • POWER PIN
On-board Charger, DC/DC Converter, Inverter unit
AP-10
High-power supply terminal, high heat resistance board-to-board connection. Contribute to miniaturization of power electronics devices, height differences can be customized.
  • BOARD TO BOARD
  • POWER PIN
AP-TSS10, AP-LT10
High current (32 A), high temperature (125 °C) Spacer/Power Terminal, PCB SMT Terminal, easily operate with SMT and M3 (8.00 mm) screws
  • POWER PIN
ISH® (Horizontal Type)
High heat and vibration resistant, horizontal, SMT connector
  • DISCRETE WIRE
ISH® (Horizontal Type-Hybrid)
High heat and vibration resistant connector with hybrid (signal + power) terminals
  • DISCRETE WIRE
ISH® (Vertical Type)
High heat and vibration resistant, vertical SMT connector
  • DISCRETE WIRE
ISH® (Wire-to-Wire Type)
High heat and vibration resistance, wire-to-wire relay connector
  • DISCRETE WIRE
IARPB® (Horizontal Type)
Vibration resistant, one-piece,horizontal type board-in connector
  • DISCRETE WIRE
IARPB® (Vertical Type)
Vibration resistant, one-piece,vertical type board-in connector
  • DISCRETE WIRE
ISFIT® (Press-Fit Terminal)
Wire-to-board/board-to-board, 4-points spring contact press-fit terminal
  • POWER PIN
  • BOARD TO BOARD
BMS
EVAFLEX® 5-SE
Auto-locking, horizontal mate, 0.5 mm pitch FFC/FPC connector
  • FPC
  • FFC
ISH® (Horizontal Type)
High heat and vibration resistant, horizontal, SMT connector
  • DISCRETE WIRE
ISH® (Horizontal Type-Hybrid)
High heat and vibration resistant connector with hybrid (signal + power) terminals
  • DISCRETE WIRE
ISH® (Vertical Type)
High heat and vibration resistant, vertical SMT connector
  • DISCRETE WIRE
ISH® (Wire-to-Wire Type)
High heat and vibration resistance, wire-to-wire relay connector
  • DISCRETE WIRE
IARPB® (Horizontal Type)
Vibration resistant, one-piece,horizontal type board-in connector
  • DISCRETE WIRE
IARPB® (Vertical Type)
Vibration resistant, one-piece,vertical type board-in connector
  • DISCRETE WIRE
ISFIT® (Press-Fit Terminal)
Wire-to-board/board-to-board, 4-points spring contact press-fit terminal
  • POWER PIN
  • BOARD TO BOARD
Telematics
MHF® I LK
Locking solution that works with MHF I receptacles, supports up to 9 GHz, mated height of 2.9 mm max
  • MICRO-COAX
MHF®-TI
Small, robust RF connector for automotive telematics antenna, and camera sensors
  • MICRO-COAX
MHF® I
Supports up to 9 GHz, mated height of 2.5 mm max. and 3.0 mm max.
  • MICRO-COAX
MHF® I (4 pads receptacle)
MHF® I receptacle with additional 4th pad improves center alignment when mounted on the board by reflow, and increases solder shear force
  • MICRO-COAX
Rear View Camera
EVAFLEX® 5-SE-G VT
One-handed auto-locking feature, high temperature (125℃), high-speed, vertical mate, 0.5 mm pitch shielded FFC/FPC connector
  • FPC
  • FFC
  • SHIELD FFC
EVAFLEX® 5-SE-G HT
One-handed auto-locking feature, high temperature (125℃), high-speed, horizontal mate, 0.5 mm pitch shielded FFC/FPC connector
  • FPC
  • FFC
  • SHIELD FFC
EVAFLEX® 5-VS
Auto-locking, high temperature option (105℃), high-speed, horizontal mate, 0.5 mm pitch shielded FFC/FPC connector
  • FPC
  • FFC
  • SHIELD FFC
EVAFLEX® 5-SE
Auto-locking, horizontal mate, 0.5 mm pitch FFC/FPC connector
  • FPC
  • FFC
MHF®-TI
Small, robust RF connector for automotive telematics antenna, and camera sensors
  • MICRO-COAX
NOVASTACK® 35-P
Robust connector with hold-down feature and Corson Alloy main contacts to transmit power lines, 0.35 mm pitch, 0.7 mm height, 2.3 mm depth
  • BOARD TO BOARD
  • POWER PIN
Roof, Door Harness
ISH® (Horizontal Type)
High heat and vibration resistant, horizontal, SMT connector
  • DISCRETE WIRE
ISH® (Horizontal Type-Hybrid)
High heat and vibration resistant connector with hybrid (signal + power) terminals
  • DISCRETE WIRE
ISH® (Vertical Type)
High heat and vibration resistant, vertical SMT connector
  • DISCRETE WIRE
ISH® (Wire-to-Wire Type)
High heat and vibration resistance, wire-to-wire relay connector
  • DISCRETE WIRE
MHF®-TI
Small, robust RF connector for automotive telematics antenna, and camera sensors
  • MICRO-COAX
IARPB® (Horizontal Type)
Vibration resistant, one-piece,horizontal type board-in connector
  • DISCRETE WIRE
IARPB® (Vertical Type)
Vibration resistant, one-piece,vertical type board-in connector
  • DISCRETE WIRE
ISFIT® (Press-Fit Terminal)
Wire-to-board/board-to-board, 4-points spring contact press-fit terminal
  • POWER PIN
  • BOARD TO BOARD
Rear Lamp
ISH® (Horizontal Type)
High heat and vibration resistant, horizontal, SMT connector
  • DISCRETE WIRE
ISH® (Horizontal Type-Hybrid)
High heat and vibration resistant connector with hybrid (signal + power) terminals
  • DISCRETE WIRE
ISH® (Vertical Type)
High heat and vibration resistant, vertical SMT connector
  • DISCRETE WIRE
ISH® (Wire-to-Wire Type)
High heat and vibration resistance, wire-to-wire relay connector
  • DISCRETE WIRE
IARPB® (Horizontal Type)
Vibration resistant, one-piece,horizontal type board-in connector
  • DISCRETE WIRE
IARPB® (Vertical Type)
Vibration resistant, one-piece,vertical type board-in connector
  • DISCRETE WIRE
ISFIT® (Press-Fit Terminal)
Wire-to-board/board-to-board, 4-points spring contact press-fit terminal
  • POWER PIN
  • BOARD TO BOARD

Related Topics

Introducing I-PEX’s New Power Supply Terminal Connector AP-10

I-PEX has launched the AP-10 high-current board to board power terminal connector that supports up to 16 Amp and high heat resistance up to 105℃ degree with a space-saving design that reduces the PCB mounting space.

MHF® LK Series / Micro RF Coaxial Connector with locking function

Locking solution that works with Micro RF connector, MHF
MHF LK Series

ISFIT® Solderless Compliant Pin Terminal

ISFIT® Solderless Compliant Pin Terminal / Press-Fit Connector Technology.
ISFIT

ISH® / Power Connector

High heat and vibration resistant connector
ISH

EVAFLEX® Series / Auto-Locking FFC/FPC Connectors

High productivity and high reliability with auto-lock design
EVAFLEX-5-SE-GHT and GVT

I-PEX High-Temperature Connector Products

I-PEX has a large lineup of general-purpose connectors rated at 85°C and products designed for consumer devices, and we have also developed a number of products that can handle high temperatures, from 105°C to 125°C.

MHF®-TI: Compact and robust RF connector for automotive telematics and infotainment

The I-PEX MHF® TI is ideal for connection with telematics, which is a communication system such as GPS and V2X, connection with infotainment system for wireless signals such as Bluetooth, and connection with driving monitoring system for face / voice recognition where there is a demand for cables and connectors that emphasize safety and are resistant to vibrations peculiar to vehicles.

I-PEX Connectors for Automotive Industry

I-PEX offers a variety of connectors that are ideal for the automotive industry. Below are some use case examples for typical automotive applications such as IGBT, PCU and BMS/CMU.

Connected Car and I-PEX MHF® I LK Micro RF Connector

The I-PEX MHF® I LK Connector is the industry's first micro RF coaxial connector with a mechanical lock. This has an additional lock covering the MHF® I Plug which helps improve retention force and enhances signal connection reliability. This solution is widely adopted by many customers especially for applications where vibration and shock are expected.
Connected car technology and MHF I LK

Wire-to-Board Connectors and Terminals

ISH® is a high heat/vibration resistant wire-to-board connector series. Horizontal, vertical, wire-to-wire and hybrid (with power terminals) types are available. Female terminals with the embedded spring provide superior contact reliability. ISFIT® is a solderless press-fit terminal with a unique design that includes a 4-point contact with an internal spring structure that provides low mating force and eliminates damage to the through-hole on the PCB. This terminal has excellent contact reliability with accurate center position alignment which helps reduce the workload of assembly operators, as well as improving the inspection process.

New Product: Vertical type added to I-PEX’s board-in connector IARPB® series (2024/July/31)

A vertical type board-in connector is being added to the I-PEX IARPB® connector series, which has been well received in the automotive market due to its light weight and compact design.
