New Connectors Development of 112Gbps PAM4 / 64Gbps PAM4 applicable for data center (2023/SEP/29)

I-PEX will exhibit at the OCP Global Summit in Santa Clara, California, USA on October 17-19, 2023. Please come visit our booth, #C6.

Enterprise TOP



Development Background


In recent years, high-speed transmission in enterprise communications equipment, such as servers, and switches, has been rapidly advancing. This has increased the need for improved signal integrity (SI) performance of the components used in each system.

In response to these demands, I-PEX has started development of new products that support 112 Gbps PAM4 and 64 Gbps PAM4 high-speed transmission. The products feature a compact design that saves space while achieving high-speed transmission. High-speed transmission cable jumper wiring reduces signal loss in board trace wiring. It is particularly suitable for jumper wiring from expansion cards such as DPU (Data Processing Units) and NIC (Network Interface Cards) that are compatible with PCle Gen5 and Gen6 used in servers. The jumper wiring contributes to the reduction of data traffic through the CEM (Card Electromechanical) slot.

I-PEX will continue to contribute to improving the reliability and performance of enterprise communication equipment by achieving further high-speed transmission.

We are pleased to introduce our new products under development and new products that have been released for mass production.

Applications: servers, switches, and other high-speed communication equipment for data center



■CABLINE®-CA IIP PLUS 64Gbps PAM4 (Under development)

By adopting paddle card technology in the cable plug part of the CABLINE® series of micro-coaxial connectors, we have increased the transmission performance from 20 Gbps NRZ to over 64 Gbps PAM4, expanding the product's application area to the enterprise market. Transmission distance has been extended by making it possible to use Twinax cable in addition to micro-coaxial cable.

CAIIPimages

Product Features

  • Support high-speed transmission 64 Gbps/lane PAM4 using paddle card technology
  • Low profile, ideal for space-constrained applications & with ZenShield® full shield cover
  • LEAPWIRE® jumper solution for Twinax cable & micro-coaxial cable
  • Mates to standard CABLINE®-CA II PLUS Receptacle(20790-060E-01/-02)
Product Specifications
Mating type Horizontal
Pitch 1.2 mm (differential pair) * 0.4 mm (signal contacts)
Pin count 60 pin (19 differential pair max)
Height 1.14 mm
Depth 8.20 mm
Width 30.95 mm
Cable Micro-coaxial AWG #38, Twinax AWG #34
Lock function With mechanical lock

Read more about our Paddle Card Technology

https://www.i-pex.com/library/white-papers/paddle-card-technology



■DUALINE®130-HB-D 112 Gbps PAM4 (Under development)

The DUALINE® series, which realizes 112 Gbps PAM4 transmission in a small and low profile, has an even narrower pitch (1.95 to 1.3 mm, *signal contact pitch 0.4 mm) than the current product (DUALINE®195-HB), and is now a horizontally mating double-row type. By doing so, we have achieved a high density of 32 lanes while occupying about half the board area compared to current models.

DUALINEs

Product Features

  • Support high-speed transmission 112 Gbps/lane PAM4
  • Double-row type, ideal for space-constrained applications
  • LEAPWIRE® jumper solution for Twinax cable
Product Specifications
Mating type Horizontal
Pitch 1.3 mm (differential pair) * 0.4 mm (signal contacts)
Pin count 64 pin (16 differential pair x 2 row = 32 pair)
Height 3.10 mm
Depth 8.70 mm
Width 26.90 mm
Cable Twinax AWG #34
Locking function With mechanical lock



■CABLINE®-CAP 64Gbps PAM4 (Mass production released)

By adopting paddle card technology in the cable plug part of the CABLINE® series of micro-coaxial connectors, we have increased the transmission performance from 20 Gbps NRZ to 64 Gbps PAM4, expanding the product's application area to the enterprise market.

CABLINECAP

Product Features

  • Support high-speed transmission 64 Gbps/lane PAM4 using Paddle Card Technology
  • Low profile, ideal for space-constrained applications
  • LEAPWIRE® jumper solution for Twinax cable in addition to micro-coaxial cable
  • Mates to standard CABLINE®-CA Receptacle(20525-#50E-02)
Product Specifications
Mating type Horizontal
Pitch 1.2 mm (differential pair) * 0.4 mm (signal contacts)
Pin count 50 pin (16 differential pair max)
Height 1.15 mm
Depth 6.86 mm
Width 25.75 mm
Cable Micro-coaxial AWG #38
Lock function With mechanical lock



White paper about our Paddle Card Technology

https://www.i-pex.com/library/white-papers/paddle-card-technology

Product page

https://www.i-pex.com/product/cabline-cap



For more information, please visit the following web pages.

Enterprise Solutions web page

CABLINE®-CAP is in mass production, but other products are currently in the prototype stage.
Please note that product specifications are subject to change.

For sample supply and detailed product information, please contact us.
