EMC Shield (ZenShield)

A second class of problems can occur when electromagnetic noise generated from the devices’ own internal digital timing signals or electronic components causes failure of other parts within the same system.  This is called an intra-system EMC, (Electromagnetic Compatibility), problem. It often causes headaches for engineers who must develop high-performance, hand-held or portable electronic devices, in which high density electronic components are mounted. I-PEX offers a number of EMC shielding connectors (ZenShieldTM) to meet various applications and design conditions.


Micro-Coaxial Connectors


CABLINE®-CA II

CABLINE-CA II0.4 mm pitch, horizontal mating type micro-coaxial connector with EMI shielding cover and mechanical lock (narrow space type)
Mated Height (mm): 1.10 max.





CABLINE®-CA II PLUS

CABLINE-CA II PLUS

0.4 mm pitch, horizontal mating type micro-coaxial connector with EMI shielding cover and mechanical lock (wider space type)
Mated Height (mm): 1.10 max.





CABLINE®-VS II

CABLINE-VS II

0.5 mm pitch, horizontal mating type micro-coaxial connector with EMI shielding cover and mechanical lock
Mated Height (mm): 1.20 max.





CABLINE®-UM

CABLINE-UM

0.4 mm pitch, right angle vertical mating type micro-coaxial connector with EMI shielding and mechanical lock
Mated Height (mm): 2.35 max. (2.20 mm nominal)







Board-to-Board (FPC) Connectors


NOVASTACK®35-HDN

NOVASTACK 35-HDN

Created for 5G mmWave module, fully-shielded with narrow design, 0.35 mm pitch
Mated Height (mm): 0.75 max. (0.70 mm nominal)





NOVASTACK®35-HDP

NOVASTACK 35-HDP

0.35 mm pitch, high-speed (20+ Gbps), fully-shielded with power contacts
Mated Height (mm): 0.75 max. (0.70 mm nominal)







FPC/FFC connectors


EVAFLEX®5-HD

EVAFLEX 5-HD

0.5 mm pitch, horizontal mating type, fully-shielded auto-locking FFC/FPC connector
Mated Height (mm): 2.20 max. (2.00 mm nominal)





CABLINE®-CA IIF

CABLINE-CA IIF

0.4 mm pitch, horizontal mating type FPC plug connector with EMI shielding cover and mechanical lock
Mated Height (mm): 1.10 max.





CABLINE®-VS IIF

CABLINE-VS IIF

0.5 mm pitch, horizontal mating type FPC plug connector with EMI shielding cover and mechanical lock
Mated Height (mm): 1.20 max.







RF connector


MHF® 7S

MHF 7S

EMC performance, ideal for 5G mmWave applications, VSWR 1.5 max at 15 Ghz in small 2.0 x 2.0 mm receptacle size
Mated Height (mm): 1.10 max.
